BlueNor, Nordic LTE and Bluetooth 5.2 Modules

Special Single pcs Prices

  • BT40: nRF5340, dual core Cortex M33 to 128 MHz, BLE 5.2 module for $7.88.

  • BT840: nRF52840 BLE 5.2 module for $6.88.

  • The $5.00 modules: nRF52832, BT832 (castellated pins); nRF52833, BM833 (42 GPIOs); BC833M (no external component required for VDD power).

  • BT832A: BLE 5.2 Module for $3.75.

  • BC805M: BLE 5.2 module, $2.50.

Flat rate shipping is available within the USA via USPS, and worldwide via FedEx or DHL International Express.

Nordic WiFi 6 and BLE 5.3 + WiFi 6 Combo Modules

nRF7002 WiFi 6 modules: WM02C, WM02E.

nRF7002 and nRF5340 combo modules: WT02E40E, WT02E40C, WT02C40C.

BT, full size Modules, all with compatible footprints, the longest Bluetooth ranges.

nRF5340 modules: BT40F, BT40, BT40E, BT40X (with a PA); no external component required.

nRF52840 modules: BT840, BT840E, BT840F (BLE range 2300 meters), BT840X, BT840XE (with a PA, BLE range> 4500 meters);

nRF52832 modules: BT832, BT832F (BLE range760 meters), BT832X, BT832XE (with a PA, BLE range, 1170 meters)

nRF52810 modules: BT832A, BT832AF (BLE range 760 meters).

BM, mini Modules, all with compatible footprint, lower cost

nRF52840 modules: BM840, BM840P;

nRF52833 modules: BM833, BM833E, BM833F;

nRF52832 modules: BM832, BM832E;

nRF52811 modules: BM833A, BM833AF;

nRF52810 modules: BM832A;

BC, compact modules, compatible footprints for the same SoC only.

nRF5340: BC40C, BC40M, BC40P (size 8.4x9.0x1.6mm);

nRF52840: BC840, BC840M, BC840E;

nRF52833: BC833M, BC833E, both crystals embedded.

nRF52832: BC832 (7.8x8.8x1.3mm, castellated pins).

nRF52805: BC805M, $2.50 each at 1 pcs, castellated pins.

Combo modules for M.2 connector

LTE-M + NB-IoT + BLE: LN60G40F (nRF9160, nRF5340), LN60G840XE (nRF9160, +21dBM nRF52840)

BLE + LoRa: M262840F (SX1262, nRF52840), M262X840XE (+29.2 dBm LoRa, +21 dBm BLE)

Modules for M.2 Connector

LTE-BLE Combo Module, LN60G840F

  • M.2 connector, 67 pins, B Key

  • Size: 42x30.mm

  • nRF9160 SICA LTE-M/NB-IoT Module

  • u.FL connector for external LTE antenna

LN60E: An u.FL connector for external GPS antenna.$29.98 each at 1K pcs.

LN60G: Integrated GPS antenna and receiver amplifier. $34.12 each at 1K pcs.

LN60E40E: LN60E with BT40E, nRF5340 BLE 5.2 module.

LN60G840F: LN60G with BT840F, nRF52840 BLE 5.2 module, $43.00 each at 1K pcs.

LN60E840E: with BT840E, nRF52840 BLE 5.2 module, $38.79 each at 1K pcs.

LN60G40F: with BT40F, nRF5340 BLE 5.2 module, integrated GPS antenna

BLE-LoRa Combo Module, M262X840XE

  • BT840XE, max. BLE TX power +21 dBm. The longest range BLE module.

  • LR62XE, max. LoRa TX power +29.21 dBm. The longest range LoRa module.

M262X840XE: BT840XE + LR62XE.

M262840F: BT840F + LR62E.

M262X40F: BT40F + LR62XE.

BLE 5.2 Modules

BC Series, BLE 5.2 Modules

BC40C, BC40M, BC40P Compact nRF5340 modules

  • No external component required, minimum host PCB area. Both crystals, both DCDC circuits integrated.

  • Dual Core Cortex M33, up to 128 MHz.

  • 48 GPIOs

  • SAR evaluated.

  • BC40C with chip antenna. Size, 8.4x11.5x1.6mm

  • BC40M with PCB antenna. Size, 8.4 (10)x12.7x1.6mm.

  • BC40P with pads for external antenna, 8.4x9x1.6mm

  • Availability: Production.

BC805M, The $2.22 nRF52805 BLE 5.2 module

  • nRF52805, Cortex M4, 64 MHz

  • 192KB flash, 24 KB RAM

  • Integrated PCB antenna, est. range: 200 meters

  • 14 castellated pins, 10 GPIOs.

  • Size: 10x14.3x1.9 mm

  • Certifications: FCC, IC, CE, TELEC, RCM, QDID.

  • $2.22 at 1K pcs

  • Availability: production.

BC832, Micro Module with Castellated Pins

  • With Nordic nRF52832 CIAA

  • Cortex M4F processor with 512 KB flash, 64KB RAM

  • integrated chip antenna;

  • Size: 7.8x8.8x1.3mm

  • Hybrid pins: 16 castellated and 20 LGA pins.

  • 30 GPIOs

  • Certification: FCC, IC, CE, TELEC, and QDID

  • Price: $5.74 each at 1K pcs

  • Availability: production

BC833M, BC833E, nRF52833 modules

  • Supports Bluetooth 5.1 Direction Finding

  • Supports BLE 5.2, Thread, Zigbee radio protocols

  • Supports BLE 5 CODED PHY.

  • With Nordic nRF52833 QDAA

  • Cortex M4F, 64 MHz, 512 KB flash, 128KB RAM

  • Both 32 MHz and 32.768 KHz crystals on board.

  • 1.7 V to 5.5 V power supply

  • 18 GPIOs, USB 2.0

  • BC833: 10x14.3x1.9mm, integrated antenna.

  • BC833E: 10x14.3 mm, u.FL connector

  • Certifications: FCC, IC, CE, TELEC, RCM, QDID.

  • Availability: production.

BC840M, BC840, BC840E compact nRF52840 modules

  • nRF52840 CKAA

  • GPIO: 48

  • Size: 7.1x12.2x1.5mm, antenna area width 10.1 mm (L-shape).

  • Range: 400 meters at 125 Kbps

  • Certifications: FCC, IC, CE, TELEC, RCM, QDID.

  • Availability: Production

  • BC840: Size, 7.1x9.2x1.5mm. Range, 12 meters at 1Mbps with an Android phone.

  • BC840E with an u.FL. Size: 7.1x12.2x1.8mm. Range with ANT060 antenna: 3400 meters at 125 kbps.

BM Series, BLE 5.2 Modules

BM modules have compatible footprint for hardware upgrade.

BM833,BM833F, BM833E, nRF52833 BLE 5.2 module

  • Supports Bluetooth 5.1 Direction Finding

  • Supports BLE 5.2, Thread, Zigbee radio protocols

  • Supports BLE 5 CODED PHY.

  • With Nordic nRF52833 QIAA

  • Cortex M4F, 64 MHz, 512 KB flash, 256KB RAM

  • Integrated high performance PCB trace antenna.

  • BM833: size 10.2x15x1.9mm, estimated range, 1400 meters at 125 Kbps

  • BM833F: size 10.2 (15mm antenna area) x20.6x1.9mm; estimated range, 2300 meters at 125 Kbps.

  • BM833E: size, 10.2x15x1.9mm;

  • 42 GPIOs.

  • Availability: Production

BM833A,BM833AF, nRF52811 BLE 5.1 module

  • Supports Bluetooth 5.1 Direction Finding

  • Supports BLE 5.1, Thread, Zigbee radio protocols

  • Supports BLE 5 CODED PHY.

  • With Nordic nRF52811 QFAA

  • Cortex M4, 64 MHz, 192 KB flash, 24KB RAM

  • Integrated high performance PCB trace antenna.

  • 32 GPIOs

  • BM833A: size, 10.2x15x1.9mm (BM833A); estimated range, 680 meters at 125 Kbps

  • BM833AF: size, 10.2 (15 antenna area) x20.6x1.9mm (L-shape); estimated range, 1400 meters at 125 Kbps.

  • Availability: Production

BM832, BM832E, nRF52832 Bluetooth 5 modules

  • SoC: Nordic nRF52832 QFAA

  • Cortex M4F processor with 512 KB flash, 64KB RAM

  • Bluetooth range between BM832: 340 meters (low interference); 270 meters (antenna height 1.52 meters).

  • Size: 10.2x15x1.9mm

  • LGA pins: 47

  • 32 GPIOs

  • Certification: FCC (+SAR), IC, CE, TELEC, RCM, Korea, QDID

  • BM832 with an integrated PCB antenna. Price: $3.92 each at 1K pcs;

  • BM832E with an u.FL. Price: $4.08 each at 1K pcs;

  • Availability: production

BM832A, nRF52810 Bluetooth 5 modules

  • SoC: Nordic nRF52810 QFAA

  • Cortex M4F processor with 192 KB flash, 24KB RAM

  • Bluetooth range: 390 meters (low interference); 270 meters (antenna height 1.52 meters).

  • Size: 10.2x15x1.9mm

  • LGA pins: 47

  • 32 GPIOs

  • Certification: FCC (+SAR), IC, CE, TELEC, RCM, Korea, QDID

  • Price: $3.00 each at 1K pcs;

  • Availability: production.

BT Series BLE 5.2 modules

BT modules have compatible footprint for hardware upgrade.

BT40F, BT40, BT40E BLE 5.2 Modules

  • Dual Core Cortex M33, up to 128 MHz.

  • Lower power consumption: 2.6 mA at RX; 3.2 mA at 0dBm TX.

  • Supports BLE 5.2, IEEE 802.15.4

  • No external component required. Both crystals, both DCDC circuits integrated.

  • Certifications: FCC, ISED, CE, RCM, TELEC, QDID. SAR evaluated.

  • Production.

BT840F, BT840, BT840E nRF 52840 BLE 5.2 Module, Secure IoT

  • SoC: Nordic nRF52840 QIAA

  • Cortex M4F processor with 1MB flash, 256KB RAM

  • Embedded ARM CryptoCell-310 cryptographic co-processor

  • Supports CODED PHY as in Bluetooth 5 specifications

  • Supports IEEE 802.15.4 Thread and Zigbee

  • Hybrid pins: 16 castellated and 45 LGA

  • 48 GPIOs

  • Certification: FCC, IC, CE, RCM, TELEC, KCC, QDID

  • Availability: production

  • BT840F: Bluetooth range (low interference): 1000 meters at 1Mbps; 2300 meters at 125 Kbps. Bluetooth range (antenna height 1.52 meters): 390 meters at 1Mbps; 640 meters at 125 Kbps. Size: 15x20.8x1.9mm.

  • BT840E with an u.FL connector for external antenna. Bluetooth range >3400 meters at 125 Kbps. Size: 14x16x1.9mm

  • BT840: short range (120 meters at 125 Kbps). Size: 14x16x1.9mm

BT840X, BT840XE, nRF 52840 BLE 5 Module with Power Amplifier

  • SoC: Nordic nRF52840 QIAA with Skyworks SKY66112.

  • Cortex M4F processor with 1MB flash, 256KB RAM

  • Embedded ARM CryptoCell-310 cryptographic co-processor

  • Supports CODED PHY as in Bluetooth 5 specifications

  • Supports IEEE 802.15.4 Thread and Zigbee

  • Size: 15x28x1.9mm

  • Hybrid pins: 16 castellated and 45 LGA

  • 45 GPIOs

  • Certification: FCC, IC, CE, RCM, QDID.

  • BT840X with an integrated PCB antenna. Price: $12.50 each at 1K pcs;

  • BT840XE with an u.FL for external antenna. Price: $12.75 each at 1K pcs.

  • Availability: Production.

BT832, BT832F nRF52832 Bluetooth 5 modules

  • SoC: Nordic nRF52832 QFAA

  • Cortex M4F processor with 512 KB flash, 64KB RAM

  • Hybrid pins: 16 castellated and 24 LGA

  • 32 GPIOs

  • Certification: FCC, IC, CE, TELEC, RCM, QDID

  • Availability: production

  • BT832: Bluetooth range, 110 meters; Size: 14x16x1.9mm; $4.46 each at 1K pcs

  • BT832F: Bluetooth range: 760 meters(low interference); 390 meters (antenna height 1.52 meters); Size: 15x20.8x1.9mm; $4.93 each at 1K pcs;

BT832XE, BT832X, nRF52832 Bluetooth 5 module with power amplifier

  • SoC: Nordic nRF52832 QFAA with Skyworks SKY66112

  • Cortex M4F processor with 512 KB flash, 64KB RAM

  • Bluetooth range with ANT060 antenna: 1350 meters; Omni directional antenna

  • Size: 15x28x1.9mm

  • Hybrid pins: 16 castellated and 24 LGA

  • 29 GPIOs

  • Certification: FCC, IC, QDID;

  • BT832X with an integrated antenna. Price: $9.69 each at 1K pcs.

  • BT832XE with an u.FL. Price: $9.87 each at 1K pcs;

  • Availability: production.

BT832A, nRF52810 Bluetooth 5 module

  • SoC: Nordic nRF52810 QFAA

  • Cortex M4 processor with 192 KB flash, 24KB RAM

  • Bluetooth range: 110 meters

  • Size: 14x16x1.9mm

  • Hybrid pins: 16 castellated and 24 LGA

  • 32 GPIOs

  • Certification: FCC, IC, CE, TELEC, RCM, QDID

  • Price: $3.43 each at 1K pcs; Special: $3.75 each at 1 pcs.

  • Availability: production

BT832AF, nRF52810 Bluetooth 5 module

  • SoC: Nordic nRF52810 QFAA

  • Cortex M4 processor with 192 KB flash, 24KB RAM

  • Bluetooth range: 760 meters (low interference); 390 meters (antenna height 1.52 meters)

  • Size: 15x20.8x1.9mm

  • Hybrid pins: 16 castellated and 24 LGA

  • 32 GPIOs

  • Certification: FCC, IC, CE, TELEC, RCM, QDID

  • Price: $3.79 each at 1K pcs;

  • Availability: production.

nRF51822 Bluetooth 4.2 Modules

BT600I, BLE Module, BT600E

  • With Nordic nRF51822 QFAB

  • Cortex M0 processor

  • 128 KB flash, 16KB RAM

  • Host mode: connects to a host via UART, uses AT Commands

  • Standalone mode: download firmware to flash memory

  • integrated chip antenna

  • Available: BT600I-21 with 256KB flash, 16 KB RAM

  • Available: BT600I-23 with 256KB flash and 32KB RAM

  • Available: BT600E with an u.FL connector for external antenna.

Download BlueNor Document
